STIHL Quickstop®

STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.

STIHL Quickstop® Plus – an additional chain braking feature

STIHL also offers an additional, manually activated chain brake on some models. This system is designed to engage when the operator’s right hand completely releases the rear handle, stopping the chain within one second. Available on some models.

Front hand guard activated either by manual movement of the hand guard forward or by inertia if there is sufficient force in the kickback. This system is designed to stop the chain within a fraction of a second.


The large throttle lockout lever activates the additional chain braking feature. The right hand must be completely removed from the rear handle. This feature is designed to stop the chain within one second.

Coast-down Brake

Only on electric chainsaws. An additional electrically controlled braking device to stop the rotating chain when the trigger is released.

WARNING: No chain brake eliminates all risk of kickback injury.
